Mobile Drum Wood Chipper 1300 with 75KW
Machine Introduction
As one of the wood processing equipment, the wood chipper is widely used in the material preparation section in the production process of textile, paper, pulp, wood-based panels and other industries.
The main cutting materials of this machine are small - diameter wood, bamboo, peeled boards and veneers, as well as the residues of harvested fuel wood.
Raw Material
Logs, small-diameter wood and branch wood are suitable for pulp mills, forestry yards, paper mills, wood chip factories, etc., and can be processed, pine, miscellaneous, poplar, fir, and raw bamboo.
Application Fields
Paper mills, power plants, medicinal material crushing, edible fungi raw material processing, machine - made charcoal materials, wood - based panels, chemical materials, landscaping, bio - organic fertilizers, agricultural materials, personal gardens, etc.
Technical Parameter
| Model | 1300 |
|---|---|
| Rotation speed (rpm) | 635 |
| Blade QTY (piece) | 6 |
| Chip size (mm) | 20-35 |
| Input size (mm) | 320x320 |
| capacity (t/h) | 13-18 |
| Main power (kw) | 75 |
| Feed + discharge motor (kw) | 3+3 |
| Disc diameter (mm) | 1300 |
| Weight (t) | 3.6 |
| Feed conveyor length (mm) | 4000 |
| Discharge conveyor length (mm) | 10000 |
Disc Chipper Machine Models
| Model | Blade qty | Capacity (t/h) | Main power (kw) |
|---|---|---|---|
| 1150 | 6 | 10-12 | 55 |
| 1300 | 6 | 13-18 | 75 |
| 1600 | 6 | 15-25 | 110 |
| 1800 | 6 | 30-40 | 160 |
