132kw 65x130 wood chip grinder
Machine Induction
132kw 65x130 tree pulverizer is by and large the usage of for crushing special form of biomass substances into cylinder spherical form scraps, the scraps measurement can be 3-12mm, the output scraps is accurate inexperienced gas strength for furnace or enterprise biomass burner.
Application of sawdust making machine
in timber processing plants, gasoline plants, fertilizer plants, chemical flora etc. Since it requires much less funding and yield faster end result and that no risk, this collection biomass hammer mill is an perfect beaten computing device equipment.
Raw materials of sawdust maker
high-efficiency hammer mill is a pulverizer specially used for raw materials crushing in the biomass fuel production process. It has two series of single spindle and dual spindle, with features of high output and efficiency. It can crush wood chips, shavings, crop and plant crude fibers, roughage, etc
Technical Data
Model | 65X130 |
---|---|
Power | 132 kw |
Capacity | 4-4.5t/h |
Product specification | 4-10mm |
Rotor quantity | 2 rotors |
Hammer quantity | 192 pcs |
Weight | 8.6t |
Dimension | 3.6x1.83x2m |
Complete set -96 pcs hammers, Fan-15KW, ?1000 cyclone, air locker, bag filter, wind pipes.
For more models
Model | Power(Kw) | Capacity(T) |
---|---|---|
65x55 | 55 | 1-2 |
65x75 | 75 | 2-2.5 |
65x100 | 90 | 2.5-3 |
65x100 | 110 | 3-3.5 |
65x120 | 132 | 4-5 |
1300x1000 | 160/185 | 6-8 |
1600x1000 | 220 | 8-10 |
