Induction of drum type wood chipper

216 55kw 6-8t/h wood chipper, it mainly used for crushing logs, small diameter wood, branches, wood, slats, wooden pallets, bamboo and other materials. The wood chipper made up by feeding conveyor, crushing chamber, motor, discharge conveyor, reinforce base, etc.

Raw Material

Various kinds of wood logs, branches, wooden pallets,building formwork, wooden square, wood offcuts,  and other forestry wood waste.

wood harvesting residues, branches, etc.

Wood processing residues (bark, slats, log waste, scrap wood planks.

The final product is 3-5cm wood chips.

Application

* Paper mills

* Furniture factory

* Power plants and boiler plants

* Biomass pellets production line

* Boiler Plants


Technical Parameter

ModelGX216
Rotor diameter (mm)650
Blade quantity (piece)2-4
Input size (mm)540 x 240
Blade rotational speed (rpm)590
Rate of feeding (m/min)38
Max material diameter(mm)220
Capacity (tph)3-5
Main power (kw)55
Feeding motor (kw)3+4
Discharging motor (kw)3+3
Oil pump motor (kw)1.5
Feeding conveyor length (mm)4000
Discharge conveyor length (mm)10000
Weight (t)4.5

For more models

ModelMax feed size
(mm)
Capacity
(t/h)
Weight
(T)
2162203-54.5
2183006-107
211340015-2511.84
